N7C Non-Isolated Constant Current LED Driver N7C

Non-Isolated Constant Current LED Driver N7C

N7C is a Non-Isolated Reliable Constant Current Driver engineered for an extended 108-380Vac input, giving it headroom beyond standard drivers for markets with less stable or higher-voltage mains. It targets the same linear mining lamp, floodlight, wall light, and shoe-cabinet applications as comparable models, but is chosen where grid conditions are more demanding. Core functions include efficiency reaching 96% with a 0.97 power factor across 60W-320W models, backed by a 5-year warranty and UL/FC certification. This resolves the pain point of drivers failing or degrading under voltage spikes common in certain regions, since its 6KV differential and common-mode surge protection is tested to the ANSI C82.77-5 standard referenced by North American utilities.  OEM/ODM support is offered for manufacturers wanting custom voltage windows, casing sizes, or lead configurations suited to proprietary fixture builds.

Form Drawing

Product Specification

Model N7C-060Y260Z N7C-080Y260Z N7C-120Y260Z N7C-160Y260Z
Power (W) 60 80 120 160
Output voltage range (Vdc) 180~260 180~260 180~260 180~260
Adjustable output current range (A) 0.19~0.28 0.26~0.37 0.39~0.56 0.52~0.74
Typical efficiency 93.00% 93.00% 94.00% 94.00%
Typical power factor (PF) 0.97 0.97 0.97 0.97
Dimensions (L × W × H) mm 147*53*34 147*53*34 159*53*34 159*53*34



Model N7C-200Y260Z N7C-240Y260Z N7C-320Y260Z
Power (W) 200 240 320
Output voltage range (Vdc) 180~260 180~260 180~260
Adjustable output current range (A) 0.65~0.93 0.77 ~1.11 1.04~1.48
Typical efficiency 95.00% 95.00% 96.00%
Typical power factor (PF) 0.97 0.97 0.97
Dimensions (L × W × H) mm 192*53*34 192*53*34 237*53*34
