X6N Cold-Resistant Programmable Smart Driver X6N

Cold-Resistant Programmable Smart Driver X6N

Rated to operate normally down to -60°C, the Cold-Resistant Programmable Smart Driver X6N is built for streetlights and industrial fixtures in harsh, cold climates where ordinary drivers struggle to start or hold output. It's widely applied in road and industrial lighting across northern and high-altitude regions. Its core function is stable, isolated constant-power output that starts reliably and holds steady in extreme cold, solving the low-temperature failures and high maintenance costs that plague ordinary drivers.

Offline programmable current adjustment lets installers configure output before deployment, with three-in-one dimming (0/1-10V, PWM, timer) for field flexibility. Protection covers short-circuit, overvoltage, and over-temperature, backed by 6kV/10kV surge protection and an IP67 housing. Output ranges 75W-320W, CE/CB certified, 5-year warranty.

Form Drawing

Product Specification

Model X6N-075M056 X6N-075M075 X6N-075M108 X6N-100M056
Power (W) 75 75 75 100
Output voltage range (Vdc) 28~56 42~75 54~108 28~56
Adjustable full-power current range (A) 1.35~2.15 1.00~1.50 0.70~1.05 1.78~2.85
Default output 28~36V/1.55A 42~50V/1.50A 54~72V/1.05A 28~49V/2.05A
Typical efficiency 0.91 0.91 0.92 0.91
Typical power factor 0.97 0.97 0.97 0.97
Dimensions (L × W × H) mm 132*68*35 132*68*35 132*68*35 138*68*35



Model X6N-100M100 X6N-100M143 X6N-150M056 X6N-150M150
Power (W) 100 100 150 150
Output voltage range (Vdc) 56~100 72~143 28~56 85~150
Adjustable full-power current range (A) 1.00~1.50 0.70~1.05 2.70~4.30 1.00~1.50
Default output 56~67V/1.50A 72~96V/1.05A 28~32V/3.10A 85~100V/1.50A
Typical efficiency 0.92 0.92 0.925 0.935
Typical power factor 0.97 0.97 0.97 0.97
Dimensions (L × W × H) mm 138*68*35 138*68*35 158*68*37 158*68*37



Model X6N-150M214 X6N-200M056 X6N-200M200 X6N-200M286
Power (W) 150 200 200 200
Output voltage range (Vdc) 115~214 30~56 120~200 156~286
Adjustable full-power current range (A) 0.70~1.05 3.57~5.70 1.00~1.50 0.70~1.05
Default output 115~143V/1.05A 30~48V/4.15A 120~133V/1.50A 156~190V/1.05A
Typical efficiency 0.935 0.93 0.935 0.935
Typical power factor 0.97 0.97 0.97 0.97
Dimensions (L × W × H) mm 158*68*37 178*68*37 178*68*37 178*68*37



Model X6N-240M056 X6N-240M240 X6N-240M343
Power (W) 240 240 240
Output voltage range (Vdc) 30~56 130~240 171~343
Adjustable full-power current range (A) 4.30~6.85 1.00~1.50 0.70~1.05
Default output 30~48V/5.00A 130~160V/1.50A 171~228V/1.05A
Typical efficiency 0.935 0.935 0.935
Typical power factor 0.97 0.97 0.97
Dimensions (L × W × H) mm 194*68*37 194*68*37 194*68*37



Model X6N-320M056 X6N-320M457
Power (W) 320 320
Output voltage range (Vdc) 28~56 228~457
Adjustable full-power current range (A) 5.71~7.50 0.70~1.05
Default output 28~56V/5.00A 228~457V/0.70A
Typical efficiency 0.94 0.95
Typical power factor 0.97 0.97
Dimensions (L × W × H) mm 244*78*42 244*78*42
